CloudEngine S5732-H Series Hybrid Optical-Electrical Switches
The S5732-H series optical/electrical hybrid switche provides independent optical/electrical working mode and optical/electrical
Checking optical and electrical ports on Huijue switches
You can check Huawei switch ports using commands like display interface for electrical ports and display transceiver for optical modules to monitor status, traffic, and diagnostics.
Checking Electrical (Ethernet) Ports
- View Interface Status Use the command:
display interface briefThis shows the physical status (up/down), protocol status, duplex mode, speed, and recent traffic statistics for all Ethernet interfaces . - Check Detailed Statistics
display interfaceThis provides packet counts, errors, discards, and bandwidth usage, helping identify issues like collisions or CRC errors . - Troubleshoot Down Ports
- Check for hardware failures (cards, cables, optical modules)
- Verify configuration consistency (negotiation mode, speed, duplex)
- Use
display logbufferto view interface logs for events causing the port to go down .
Checking Optical Ports (SFP/Transceivers)
- View Optical Module Information
display transceiverdisplay transceiver interfaceThis shows module type, connector type, wavelength, transfer distance, vendor info, and digital diagnostic monitoring (DDM) support . - Check Receive and Transmit Power
display transceiver interfaceThis provides current RX/TX power, voltage, bias current, and temperature, along with high/low thresholds for alarms .verbose - Module Compatibility and Authentication
- Use Huawei-certified optical modules to ensure accurate readings and avoid interface damage .
- Non-certified modules may cause data bus errors, short circuits, or incorrect diagnostics.
Best Practices
- Always verify the interface type and number before running commands.
- Monitor both physical and protocol status; a port may be physically up but protocol down if IP or configuration issues exist .
- Regularly check optical power levels to detect fiber degradation or module issues early .
- Use remote management tools like PuTTY, SecureCRT, or Xshell for console access . By combining these commands and checks, you can effectively monitor, troubleshoot, and maintain both electrical and optical ports on Huawei switches.
