South Asia Pipeline 24-core Optical Cable Model

The South Asia Pipeline 24-core optical cable is typically an OPGW or ADSS type, designed for high-voltage overhead transmission with robust mechanical and environmental protection.

Cable Types and Structure

1. OPGW (Optical Ground Wire) 24-Core Cable

• Purpose: Dual-function cable for grounding and telecommunications on high-voltage lines (66kV–500kV)
• Optical Core: 24 single-mode fibers compliant with ITU-T G.652, operating at 1310 nm / 1550 nm with attenuation of 0.35 dB/km and 0.25 dB/km respectively
• Construction: Central stainless steel tube containing optical fibers, surrounded by aluminum-clad steel (ACS) or aluminum alloy wires for mechanical strength and lightning resistance
• Protection: PBT loose tube with hydrogen-absorbing gel, glass fiber and aramid reinforcement, aluminum tube sheath
• Advantages: High short-circuit current capacity, corrosion resistance, suitable for coastal or chemically aggressive environments, supports relay protection and automatic transmission systems 2. ADSS (All-Dielectric Self-Supporting) 24-Core Cable
• Purpose: Fiber optic communication without conductive metal, can be installed on live high-voltage lines
• Construction: Loose tube filled with water-blocking compound, reinforced with two layers of aramid fibers, extruded with polyethylene (PE) or electric tracking-resistant sheath
• Features: Lightweight, small diameter, excellent tensile strength, maximum span over 1000 meters, suitable for 35kV–220kV lines
• Advantages: Can be erected without electricity, resistant to ice, wind, and environmental stress, ideal for overhead crossings of rivers, valleys, and lightning-prone areas 3. Armored GYTY53 24-Core Cable
• Purpose: Direct-burial or long-distance outdoor fiber optic transmission
• Construction: Loose tube with water-resistant gel, central steel wire strength member, double PE jacket with steel tape armor
• Features: Excellent crush and rodent resistance, stress-free fiber movement, operating temperature -40°C to +60°C
• Applications: Long-distance pipelines, LAN, and backbone networks requiring high mechanical protection

Key Considerations for Pipeline Deployment

• Mechanical Strength: Must withstand tension, wind, ice, and tower load
• Environmental Resistance: Corrosion, UV, and chemical resistance for coastal or industrial areas
• Electrical Compatibility: OPGW provides grounding and lightning protection; ADSS is dielectric and safe for live-line installation
• Installation: OPGW and ADSS can be mounted on existing high-voltage towers; armored cables are suitable for direct burial or duct installation In summary, the South Asia Pipeline 24-core optical cable is engineered for high reliability, dual-purpose communication and grounding, and environmental resilience, with options including OPGW for high-voltage overhead lines, ADSS for dielectric self-supporting installations, and armored GYTY53 for underground or high-protection applications .
