Fire-retardant paint for cable tray surfaces

Fire-retardant paint on cable trays provides a protective coating that slows flame propagation, maintains circuit integrity, and enhances safety in electrical installations.

Purpose and Mechanism

Fire-retardant paints are specialized coatings designed to slow down or prevent the spread of fire along electrical cables and trays. When exposed to heat, these paints undergo chemical reactions—either intumescent (swelling to form an insulating char) or ablative (sacrificially burning away)—which create a barrier that protects the underlying cables from ignition and flame propagation. This is critical because electrical fires can spread rapidly and release toxic fumes, posing serious risks to both infrastructure and personnel (119 Fire Control), .

Types of Fire-Retardant Coatings

• Water-based intumescent paints: Expand upon heating to form a protective char, providing up to several hours of circuit integrity. Examples include ALTIC 007, which can expand up to 10 times its thickness and is suitable for both indoor and outdoor applications, resistant to water, oil, UV, and chemicals (ALTIC Paint), .
• Self-extinguishing coatings: Products like AF Cable Coat release water vapor when exposed to fire, lowering temperature and leaving a non-combustible residue that limits fire spread along cable lines (AF Systems), .
• Fire protection tapes and coatings: Solutions such as FLAMMOTECT-A and DG-CR 0.7 provide a robust shield around cables and trays, enhancing resistance to environmental factors while preventing flame propagation (Flamro), .

Application Guidelines

• Compatibility: Water-based paints are generally safe for use on LSOH (Low Smoke Zero Halogen) cables, whereas oil-based paints can degrade PVC or LSOH sheaths, increasing brittleness and smoke production (Prysmian UK), .
• Coverage: For horizontal cable trays, some products recommend applying the coating at intervals (e.g., every 20 meters) to ensure effective fire suppression (AF Systems), .
• Environmental resistance: Many modern fire-retardant paints are designed to withstand UV, moisture, oil, and chemical exposure, making them suitable for both indoor and outdoor installations (ALTIC Paint, Flamro), .

Standards and Certification

Fire-retardant paints for cables and trays are often tested and certified according to international standards such as IEC 60332-3-10, IEC 60332-3-22, ASTM, and NFPA, ensuring reliable performance in fire scenarios (AF Systems, ALTIC Paint), . Certification ensures that the coating maintains circuit integrity for a specified duration, typically ranging from 30 minutes to 4 hours depending on the product.

Benefits

• Enhanced fire safety: Slows flame spread and reduces the risk of catastrophic electrical fires.
• Protection of critical systems: Maintains power and communication lines during fire events.
• Compliance: Meets regulatory and safety standards for industrial, commercial, and sensitive installations.
• Environmental durability: Resistant to moisture, UV, chemicals, and temperature variations. In summary, applying fire-retardant paint on cable trays is a proactive safety measure that protects electrical infrastructure, ensures compliance with fire safety standards, and provides critical time for evacuation and firefighting in case of fire. Selecting the appropriate water-based, intumescent, or self-extinguishing coating and following manufacturer guidelines ensures optimal performance and long-term reliability.
