Power system protection
Overlapping protection zones: single-line diagram depicts generators at the top connected to voltage transformers, (vertical)
1. Plug Setting Multiplier (PSM) PSM, or Plug Setting Multiplier, represents how many times the actual current exceeds the relay's pickup current. It is calculated as the ratio of fault current in the relay to its pickup current and is crucial for determining the relay's operating time on IDMT (Inverse Definite Minimum Time) curves. A higher PSM results in faster tripping, while a lower PSM delays operation, allowing proper coordination with upstream and downstream relays . 2. Time Setting Multiplier (TSM) TSM scales the base operating time derived from the relay's characteristic curve. By adjusting TSM, engineers can control the actual trip time of the relay to achieve selective coordination. A lower TSM results in faster tripping, while a higher TSM delays the relay to provide backup protection for upstream devices . 3. Current Setting / Pickup Current The pickup current is the minimum current at which the relay begins to operate, overcoming the controlling force of the relay. It is adjustable by changing the number of active turns in the relay coil and is expressed as a percentage of the CT's rated secondary current. This setting ensures the relay responds only to currents above a defined threshold . 4. Earth Leakage / Earth Fault Setting (EL) EL defines the current level at which the relay detects earth faults. It ensures that leakage currents or ground faults are identified and isolated to prevent equipment damage or hazards . 5. Overload Setting (OL) OL is used in thermal overload relays to protect equipment from sustained overcurrent conditions. It determines the current level at which the relay will trip to prevent overheating . 6. Multiplying Factor (MF) MF, also called the metering or scaling factor, adjusts the relay's response based on CT ratios or system scaling requirements. It ensures that relay settings remain accurate when CTs or system parameters change .
Relay protection settings are coordinated to ensure selective tripping. PSM determines the sensitivity to fault current, TSM adjusts the timing, and EL/OL/MF fine-tune the relay's response for specific fault types or system configurations. Properly configured settings allow downstream relays to trip first for local faults, while upstream relays provide backup protection, maintaining system stability and minimizing unnecessary outages .
If an overcurrent relay is connected to a CT with a rated secondary current of 1 A and the desired pickup is 125% of rated current, the relay's pickup current is set to 1.25 A. If a fault occurs with a secondary current of 5 A, the PSM is 5 / 1.25 = 4. The relay's operating time is then determined using the IDMT curve multiplied by the TSM to achieve the desired coordination . These settings are essential for reliable, fast, and selective protection of electrical systems, ensuring faults are cleared efficiently without affecting healthy parts of the network.
