Huawei Switch 1G Fiber Port

Huawei switches support 1G fiber connections via SFP (1000BASE-X) ports using compatible SFP modules for single-mode or multimode fiber.

1G Fiber Port Overview

Huawei switches feature SFP ports (small form-factor pluggable) that allow 1 Gbit/s fiber connectivity over various distances and fiber types. These ports are hot-pluggable and can accommodate different SFP modules depending on the network requirements . By default, 1000BASE-X interfaces operate at 1 Gbit/s, and higher speeds (like 10G) require a license and specific commands .

Compatible SFP Modules

Huawei offers a range of 1G SFP modules for fiber connections, including:

• SFP-GE-LX-SM1310: Single-mode, 1310nm, up to 20 km
• eSFP-GE-SX-MM850: Multimode, 850nm, short-range (220m–500m)
• S-SFP-GE-LH40-SM1310: Single-mode, 1310nm, up to 40 km
• Other variants cover wavelengths from 850nm to 1550nm and distances from 220m to 80 km .

These modules are compatible with Huawei switches and other hardware supporting 1000BASE-LX or SX standards. Third-party modules, such as BlueOptics SFP-1G-LX-20KM-HU, are also compatible and tested for full functionality with Huawei switches .

Configuration Considerations

• Default speed: 1 Gbit/s for 1000BASE-X ports. To upgrade to 10 Gbit/s, a license is required, and the assign port-type xge command must be applied, followed by a device restart .
• Port type check: Use display device port-type configuration to verify the current interface speed and configuration .
• SFP vs SFP+: 1G SFP modules can run in SFP+ ports at 1G speed, but the port may lock at 1G until reloaded or configured .

Deployment Tips

• Fiber type selection: Use multimode fiber for short distances (up to 500m) and single-mode fiber for longer distances (up to 80 km).
• Wavelength matching: Ensure the SFP module wavelength matches the fiber type and distance requirements.
• Monitoring: Enhanced SFP (eSFP) modules provide optical power monitoring for better network management .

Huawei 1G fiber ports provide flexible, reliable connectivity for enterprise networks, supporting both short-range and long-range fiber links with a variety of SFP modules. Proper module selection and configuration ensure optimal performance and compatibility.
