45-degree angle fabrication of galvanized cable trays

To fabricate a 45-degree bend in a galvanized cable tray, precise V-cut measurements and careful bending along the centerline are required to ensure proper alignment and structural integrity.

Fabrication Method

1. Marking the Tray:

• Identify the centerline of the cable tray where the bend will occur.
• For a 45-degree bend, calculate half the angle (22.5°) to determine the V-cut width on each side of the centerline. For example, in a 100 mm wide tray, each side of the V-cut would be approximately 41.42 mm from the centerline .
• It is recommended to test the cut on cardboard or scrap material first to verify dimensions. 2. Cutting the Lip:
• Remove the flanged edge along the marked V-cut area.
• File or trim the lip to allow the cut edges to overlap smoothly during bending . 3. Bending the Tray:
• Fold the tray along the centerline so that the cut edges overlap, forming the 45-degree angle.
• Ensure the bend is uniform and the tray maintains its structural integrity. 4. Verification and Adjustment:
• Check the angle with a protractor or angle gauge.
• Adjust the overlap or filing as needed to achieve a precise 45-degree bend.

Tools and Calculators

• Online Cable Tray Slope & Fabrication Calculators can simplify the process by providing V-cut dimensions, slope length, and hanger spacing for preset angles like 45° .
• These tools generate to-scale SVG diagrams for direct marking, reducing errors during on-site fabrication.

Material Considerations

• Galvanized trays can be pre-galvanized or hot-dip galvanized after fabrication. Ensure that bending does not compromise the protective coating .
• Use appropriate gloves and bending tools to avoid damaging the galvanized surface.

Practical Tips

• Always measure twice and cut once to avoid material waste.
• For larger trays, consider using mechanical bending equipment to maintain uniformity.
• Ensure that the bent section aligns with brackets and supports to maintain proper load distribution . By following these steps and using calculators or templates, a precise 45-degree bend in galvanized cable trays can be achieved efficiently and safely.
