Models of fiberglass cable trays

Fiberglass cable trays come in several models, including ladder, trough, solid-bottom, perforated, and epoxy resin composite types, each designed for specific cable support and environmental needs.

Ladder Type

Ladder-type fiberglass cable trays consist of two side rails connected by transverse rungs, resembling a ladder. This open design allows excellent ventilation and heat dissipation, making it ideal for power cables and large-diameter control cables. They are commonly used in industrial plants, substations, and power distribution systems. Ladder trays are easy to install and modify, and they come in various rung spacing and load classes for light, medium, and heavy-duty applications .

Trough or Channel Type

Trough or channel trays feature a bottom plate with side rails, providing more protection than ladder trays while still allowing some ventilation. They are suitable for control, communication, and instrumentation cables that require shielding from dust or falling objects. Optional covers can be added for outdoor or dirty environments, making them a versatile choice for computer and sensitive signal cables .

Solid-Bottom Type

Solid-bottom fiberglass trays have a fully closed bottom and continuous side walls, offering the highest level of protection against dust, liquids, and mechanical damage. They are ideal for commercial buildings, tunnels, and transportation projects, especially where cables must be completely isolated from the environment. Cover plates can further enclose the tray to form a near-complete duct .

Perforated Type

Perforated trays have holes or slots along the bottom and sides, allowing air circulation and drainage. This design reduces heat and moisture buildup around cables. They are commonly used in commercial and light industrial applications where moderate cable support and ventilation are required .

Epoxy Resin Composite Type

Epoxy resin composite trays combine an inner metal skeleton with an outer FRP body, offering a balance of mechanical strength and corrosion resistance. These trays are suitable for environments where both structural support and chemical resistance are critical .

Summary

Fiberglass cable trays are chosen based on cable type, environmental exposure, load requirements, and ventilation needs. Ladder trays excel in ventilation and heavy-duty support, trough and perforated trays provide moderate protection with airflow, solid-bottom trays offer maximum protection, and epoxy resin composite trays combine strength with chemical resistance. Each model ensures long service life, low maintenance, and corrosion resistance, making FRP trays ideal for industrial and commercial installations .
