Dimensions of Oman High Voltage Distribution Box

High voltage distribution boxes in Oman typically vary in size, with common dimensions around 280 x 170 x 125 mm for smaller units, while larger industrial or outdoor enclosures are customized to meet IEC and local standards.

Standard Dimensions

Distribution boxes in Oman are designed to accommodate various electrical components such as circuit breakers, fuses, and protective devices. A commonly cited size for a standard electrical distribution box is 280 mm (height) x 170 mm (width) x 125 mm (depth), made from powder-coated metal for durability and corrosion resistance . However, high voltage or industrial-grade boxes often have larger dimensions to house multiple incomers, bus bars, and MCB/ELCB/MCCB assemblies, and these are typically customized based on the facility's power requirements .

Design Considerations

• Ingress Protection (IP Rating): Outdoor and high-voltage boxes are usually rated IP65 or higher, ensuring protection against dust, sandstorms, and water jets, which is critical in Oman's desert and monsoon-prone regions .
• Material: Enclosures are made from UV-stabilized thermoplastics or powder-coated metal alloys to withstand extreme heat and prevent warping or corrosion .
• Mounting Options: Boxes can be wall-mounted, flush, or surface-mounted, with cable entry options from the top or bottom to facilitate installation .
• Compliance: All boxes must comply with Oman's Public Authority for Electricity and Water (PAEW) regulations and international standards such as IEC 61439-3 for low voltage switchgear assemblies .

Variants

• Residential/Office Boxes: Smaller, compact units with integrated MCBs for circuit control.
• Industrial/Factory Boxes: Heavy-duty enclosures with larger dimensions to accommodate complex power distribution and higher amperage ratings.
• Outdoor/Temporary Boxes: Designed for harsh environmental conditions, often with higher IP ratings and thermal resistance. In summary, while a typical small distribution box in Oman measures 280 x 170 x 125 mm, high voltage and industrial boxes are larger and customized to meet operational, safety, and environmental requirements, ensuring reliable power distribution across residential, commercial, and industrial applications .
